HLRTopoBRep_DataMapIteratorOfDataMapOfShapeFaceData
Introduction
HLRTopoBRep_DataMapIteratorOfDataMapOfShapeFaceData is used to iterate over a map of HLRTopoBRep_DataMapOfShapeFaceData which contains a relation between TopoDS_Shape and HLRTopoBRep_FaceData.
HLRTopoBRep_FaceData consists of three shape lists; internal outLines, outLines on restriction and ISO lines.
- Internal outlines
This consists of a list of wire shapes that defines the internal boundaries of the face. The internal boundary of a face is a set of wires that defines the holes or cutouts in a face (eg: circular hole). - Outlines on restriction
This is a list of the wire shapes that define the boundary of the face on a restricted set of edges. The OutlinesOnRestriction shape list stores the wire shapes that define the boundary of the face on this subset of edges.- Iso Lines
This is a list of the curve shapes that define the isometric curves on the given face.
Example
Here is an example of how to use the HLRTopoBRep_DataMapIteratorOfDataMapOfShapeFaceData class.
#include <HLRTopoBRep_DataMapIteratorOfDataMapOfShapeFaceData.hxx>
// list of HLRTopoBRep_VData objects
HLRTopoBRep_DataMapOfShapeFaceData map;
// initialize the iterator
HLRTopoBRep_DataMapIteratorOfDataMapOfShapeFaceData itr(map);
for (; itr.More(); itr.Next())
{
const TopoDS_Shape shape = itr.Key(); // key
HLRTopoBRep_FaceData data = itr.Value(); // value
const TopTools_ListOfShape& intL = data.FaceIntL(); // internal outlines
const TopTools_ListOfShape& outL = data.FaceOutL(); // outlines on restrictions
const TopTools_ListOfShape& isoL = data.FaceIsoL(); // Iso lines
}
